Specifications

42" Magnetic Chuck Diameter,
22 to 24" Approximate Range Over Chuck With New Wheel
22" Diameter of Wheel Chuck,
Cortland 5 Segment Wheel
48" Swing Inside Water Guards
720 RPM Wheel Speed
(6) Ranges of Chuck Speeds 5,7,10,15,20 & 27 RPM
Automatic Downfeeds Feed 0 to 70 IN/MIN
50 HP, 3 Phase, 60 Cycle, 440 Volt, 705 RPM
Floor Space: 13.5"L x 8.4"W
Height: 8.7" Min., 9.1" Max.
Approx. Weight: 14,250 lbs.

Scope of Work:

Check table flatness.

Tram spindle to table.

Grind table flat.

Test grind parts.

Run machine for 8 hr.

Run-off machine.
